3
PEM-X1
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC 2326020
Table of Contents
1 ABOUT THIS MANUAL 6
1.1 Preface 6
1.2 Warnings, Notices, and Symbols in this Operating Manual 6
1.3 Languages 7
1.4 Abbreviations 7
2 CORRECT USE 8
2.1 Device Type 8
2.2 Type of Use 8
2.3 Use in Potentially Explosive Areas 8
2.4 Safety Parameters 9
2.5 Processible Working Materials 9
2.6 Reasonably Foreseeable Misuse 10
2.7 Residual Risks 10
3 IDENTIFICATION 11
3.1 Explosion Protection Identi cation 11
3.2 Permissible Device Combinations 11
4 GENERAL SAFETY INSTRUCTIONS 12
4.1 Safety Instructions for the Operator 12
4.1.1 Electrical Devices and Equipment 12
4.1.2 Sta Quali cations 12
4.1.3 Safe Work Environment 12
4.2 Safety Instructions for Sta 13
4.2.1 Safe Handling of WAGNER Powder Spray Devices 13
4.2.2 Grounding the Device 13
4.2.3 Product Hoses 13
4.2.4 Cleaning 14
4.2.5 Handling Powder Lacquers 14
4.3 Information About Safe Discharges 15
4.4 Protective and Monitoring Equipment 16
5 DESCRIPTION 17
5.1 Spray Gun Design 17
5.2 Functioning of the Spray Gun 17
5.3 Technical Data 18
5.3.1 Dimensions 19
5.4 Permitted Accessories 20
5.5 Scope of Delivery 20
6 ASSEMBLY AND COMMISSIONING 21
6.1 Training Assembly/Commissioning Sta 21
6.2 Storage Conditions 21
6.3 Installation Conditions 21
6.4 Preparing the Spray Gun 22
6.4.1 Selection of the Suitable Nozzle System 22
6.5 Connecting the Spray Gun 24
6.6 Grounding 26
6.6.1 Grounding the Powder Coating System 27
