PEM-X1
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC 2326020
Dimensions:
Length/width/height see Chapter 5.3.1
Weight 490 g; 1.08 lbs
Electrical:
Input voltage maximum 22 Vpp
Input current maximum 0.9 A
Frequency 19 - 30 kHz
Output voltage maximum 100 kV DC
Maximum Corona current 120 μA
Polarity negative
Construction type in accordance with EN 50050-2
Protection class
Pneumatic:
Input air pressure (atomizing air volume) maximum 3 bar; 0.3 MPa, 43.51 psi
Powder output quantity maximum 450 g/min;
maximum 0.99 lbs/min
Ambient conditions:
Operating temperature range 5 - 45 °C; 41 - 113 °F
Relative humidity
5.3 TECHNICAL DATA
Ambient conditions:
If low-melting powders are used, the ambient temperature may have to be lower than
30 °C; 86 °F.
Volume measures:
for volumes speci ed in Nm³ (standard cubic meters). One cubic meter of a gas at 0 °C and
1.013 bar is called norm cubic meter.
Outgoing air containing oil!
Risk of poisoning if inhaled.
Insu cient paint application quality.
Provide compressed air free from oil and water
(Quality Standard 3.5.2 according to ISO 8573.1)
3.5.2 = 5 μm / +7 °C; 44.6 °F / 0.1 mg/m³.
WARNING
