Waters 2545 Binary Gradient Module User Manual

1-12 Setting up the 2545 Binary Gradient Module
Installing seal-wash solvent supply tubes
Each seal-wash solvent supply tube is pre-assembled with a free-sliding
PEEK compression screw, stainless steel collar, and yellow ferrule. Be careful
not to lose these parts when working with these tubes.
Required material
Seal-wash inlet tube assembly (part number 430000576)
To install the seal-wash solvent supply tubes:
1. Insert the seal-wash solvent supply tube into the top port of the pump A
seal-wash pump. Ensure the tube is pressed into the pump before
tightening the compression screw to set the ferrule.
Caution: Do not re-use the solvent inlet tube ferrule more than two
times. Re-use may result in slow leaks. Cut the end of the tube
squarely and use a new ferrule. The nut can be re-used.
Warning: To avoid possible harmful vapors, position solvent
containers in a safe place, such as in a fume hood or under a
counter vented to the outside.
!
