June 28, 2016, 715003956 Rev. C
Page 49
Required materials:
• Chemical-resistant, powder-free gloves
• Tray on which to place the pump
• Container to catch used oil
• Suitable pump oil
To add oil to the backing pump:
1. Power-off the instrument using the power button in the top, left-hand corner of the front
panel.
2. Wait for approximately 5 minutes to allow the instrument to vent.
3. Switch off the pump, and disconnect the power cable.
4. Place the pump on a tray suitable for catching dripping oil.
5. Remove the oil-drain plug from the pump’s rear panel.
Warning: To avoid personal contamination with biohazards or toxic materials in used pump oil,
always wear chemical-resistant, powder-free gloves while performing this procedure.
Warning: To avoid burn injuries, allow the pump to cool before touching surfaces
displaying the burn warning symbol.
