Installing and removing the corona pin 4-13
Corona pin mounting contact:
4. Fit the corona pin to the mounting contact, ensuring that the corona pin
is securely mounted.
Warning: The corona pin tip is sharp. To avoid puncture wounds,
handle it with care.
TP03130
Corona pin mounting
contact blanking plug
