4-14 Maintenance Procedures
Corona pin:
5. Close the source enclosure.
6. Look through the source window, and use the vernier probe adjuster to
position the probe tip so that it is pointing approximately midway
between the tips of the sample cone and corona pin.
TP03130
Corona pin
