Watlow F4T Install & Troubleshooting 41 Chapter 6 Appendix
Chapter 6: Appendix
F4T Base Specifications
Line Voltage/Power (Minimum/Maximum Ratings)
High voltage option: 100 to 240V~ (ac) 50/60Hz
Low voltage option: 24 to 28V (~ ac) (Î dc), 50/60Hz
Power consumption: 23 W, 54VA maximum
Environment
NEMA 4X/IP65 - front panel mount conguration only
0 to 122°F (-18 to 50°C) operating temperature
-40 to 185°F (-40 to 85°C) storage temperature
0 to 90% RH, non-condensing
Agency Approvals
UL
®
/EN 61010 Listed, File E185611 QUYX
UL
®
508 Reviewed
CSA CC.C#14, File 158031
FM Class 3545 (congurations with limit modules)
AMS 2750 E compliant: Analog input process values. Tip: Maximize eld calibration accu-
racy and uniformity by using advanced F4T features such as Calibration Offset and Linear-
ization Function Blocks. Refer to user manual for details.
RoHS by design, China RoHS Level 2, W.E.E.E.
CE
Windows
®
Hardware Certication
User Interface
4.3 inch TFT PCAP color graphic touch screen
LED backlife >50K hours
4 keys: Home, Main Menu, Back, Help
Control Loops
1 to 4 PID or ON-OFF control loops
0 to 6 Limit loops
User-selectable action: heat, cool or heat/cool
Auto-tune with TRU-TUNE+ adaptive control
Control Loops and Over-temperature Limits
Input sampling: 10Hz
Output update: 10Hz
