When WAZER Pro is turned on, the Control Panel /UI Screen will present two options:
• Select Cut File: This allows you to select a Cut File from the SD card and initiate a Cut.
• Setup & Maintenance: This allows you to choose from several setup and maintenance
options that will aid in the upkeep of WAZER Pro.
This is the main menu of the WAZER Pro. The “>” symbol on the left indicates the current
selectable field. The OK Button confirms a selection. Pressing the Left-Arrow key will take you back
to the previous menu.
If you remove the Right-Side Access Panel and observe the Control Box, all four of the
LEDs on the left side will be on, the top and bottom lights of the middle column will be on, and the
two middle LEDs of the middle column will be flashing. None of the LEDs on the right side will be
on. WAZER Pro will not be making any noise at this point.
If your WAZER Pro fails to turn on, check the high and low float switch on the right side of the tank;
the low switch should be submerged and the high switch should not be. Adjust the water level as
needed.
Now that you have your WAZER Pro turned on we can use it to conduct the final two setup steps
prior to starting your first cut. The first is priming your plumbing to ensure the lines are purged of
any air pockets. The second is establishing your WAZER’s water level.
Priming the Plumbing
Required for initial WAZER Pro setup and restart after maintenance
This procedure will ensure that both the low-pressure and the high-pressure water lines have no air in
them and are fully primed with water, setting up your machine to have an error free and flawless cut. This
will take you less than 5 minutes but if it is not done, you may have your cut interrupted by water leveling
errors or an abrasive clog.
You may need to conduct it in the future under certain conditions:
• If the tank is drained, the low-pressure system should be re-primed.
• If the water input hose or high-pressure hose lines are disconnected,
the high-pressure system should be re-primed.
To Prime the Low-Pressure System:
• Fill WAZER Pro tank to the upper surface of Cut Bed as instructed
• Open Drain Filter Cover, tap Drain Filters to let trapped air escape. You will see bubbles coming out.
• Turn WAZER Pro on.
• Remove the front tank cover.
• Select the “Setup & Maintenance” on the Control Panel.
• Select “Maintenance”> “used Abr. Collect”. Let WAZER Pro operates in this mode for 3 minutes.
• During this period observe the outlets of the used abrasive collection system. You should see the water
stream go from being weak and turbulent to a steady and strong stream.
• Move the left side, operate the Abrasive Pick Up Line Purge Valves one-by-one for a short while. Make
sure the purge valves are closed after operating.
• Contact WAZER support if any problems or abnormal observations appear.
Note 5 Pg.18
Note 4 Pg.17
