3.3.4 RFI Filters
To be used only if necessary to comply with conducted emission levels Category C3 daccording to IEC/EN61800-3.
The models bellow are from the manufacturer Epcos.
Table 3.12: Conducted and radiated emission levels and further information
Converter Model
(with built-in RFI filter)
External RFI Filter Part Number
(manufacturer Epcos)
CFW110142T2O...RB... B84143B0150S020
CFW110180T2O...RB... B84143B0180S020
(1)
CFW110211T2O...RB... B84143B0250S020
(2)
CFW110105T4O...RB... B84143B0150S020
CFW110142T4O...RB... B84143B0150S020
CFW110180T4O...RB... B84143B0180S020
(1)
CFW110211T4O...RB... B84143B0250S020
(2)
CFW110242T4O...RB... B84143-B0250-S020
CFW110312T4O...RB... B84143-B0320-S020
CFW110370T4O...RB... B84143-B0400-S020
CFW110477T4O...RB... B84143-B0600-S020
CFW110515T4O...RB... B84143-B0600-S020
CFW110601T4O...RB... B84143-B0600-S020
CFW110720T4O...RB... B84143-B1000-S020
CFW110760T4O...RB... B84143-B1000-S020
CFW110053T6O...RB... B84143B180S081
CFW110063T6O...RB... B84143B180S081
CFW110080T6O...RB... B84143B180S081
CFW110107T6O...RB... B84143B180S081
CFW110125T6O...RB... B84143B180S081
CFW110150T6O...RB... B84143B180S081
CFW110170T6O...RB... B84143B0320S21
CFW110216T6O...RB... B84143B0320S21
CFW110289T6O...RB... B84143B0320S21
CFW110315T6O...RB... B84143B0320S21
CFW110365T6O...RB... B84143B0320S21
CFW110435T6O...RB... B84143B0320S21
CFW110472T6O...RB... B84143B0320S21
(1) For converter/filter surrounding air temperature higher than 40 °C (104 °F) and continuous output current higher than 172 Arms, it'srequired to use
B84143B0250S020 filter.
(2) For converter/filter surrounding air temperature of 40 °C (104 °F) and HD applications (heavy duty cycle, output current < 180 Arms), it's possible to use
B84143B0180S020 filter.
