WEG CFW-11 RB - Mechanical Data

8
Technical Specifications
8-8 | CFW-11 RB
8
8.3 MECHANICAL DATA
Frame Size E
650,0 [25.59]
10,0
[0.39]
52,5 [2.07]
B
R4,6 [0.18]
A
R4,60
[0.18]
15,0
[0.59]
R10 [0.39]
52,5
[2.07]
14,0
[0.55]
200,0
[7.87 ]
M8 (4X)
200
[7.87 ]
A
B
358,3 [14.1]
190,3
[7.49 ]
168,0
[6.61]
Ø51,3 [2.02] (3x) Knockout
314,0 [12.36]
157,0
[6.18]
280,0 [11,02]
274,5 [10,81]
220,5 [8,7]
67,8 [2,67]
216,0 [8.50]
Ø28,5 [1.12] (2x) Ø64,0 [2.52] (2x)
242,4 [9.55]
212,5 [8.37]
334,4 [13.16]
205,4 [8.09]
488,1 [19.22]
619,8 [24.40]
15,1 [0.59]15,1 [0.59]
312,7 [12.31]
675,0 [26,57]
Figure 8.2: Frame size E dimensions - mm [in]
