Installation and Connection
3-2 | CFW-11 RB
3.1.2 Mounting Considerations
Consult the converter weight at Table 8.1 on page 8-2 to Table 8.4 on page 8-5.
Mount the converter in the upright position on a flat and vertical surface.
External dimensions and fixing holes position according to Figure 3.1 on page 3-3 and Figure 3.2 on page 3-4.
Refer to Section 8.3 MECHANICAL DATA on page 8-8, for more details.
First, mark the mounting points and drill the mouting holes. Then, position the converter and firmly tighten the
screws in all four corners to secure the converter.
Minimum mounting clearances requirements for proper cooling air circulation are specified in Figure 3.3 on page
3-5 and Figure 3.4 on page 3-6 .
Do not install heat sensitive components right above the converter.
ATTENTION!
When arranging two or more converters vertically, respect the minimum clearance A + B (Figure 3.3
on page 3-5 and Figure 3.4 on page 3-6) and provide an air deflecting plate so that the heat rising
up from the bottom converter does not affect the top converter.
ATTENTION!
Provide conduit for physical separation of the signal, control, and power conductors (refer to Section
3.2 ELECTRICAL INSTALLATION on page 3-12).
