General Information
CFW-11 RB | 2-9
2.4 IDENTIFICATION LABELS FOR THE CFW-11 RB
There are two identification labels, one complete nameplate is affixed at the side of the converter and a simplified
label is located under the keypad. The label under the keypad allows the identification of the most important
characteristics of the converter even if they are mounted side-by-side.
1
2
1 - Nameplate affixed to the side of the heatsink
2 - Nameplate under the keypad
Figure 2.6: Location of the identification labels
