WEG CFW-11 RB User Manual

2
General Information
2-10 | CFW-11 RB
MOD.: EUCFW110601T40RBZ
MAT.: 12784255
OP.: 8888888888
PESO/WEIGHT: 162 kg (357 lb)
SERIAL#.: 8888888888
MAX. TA: 45 °C (113 °F)
LINK DC
FABRICADO NO BRASIL
HECHO EN BRASIL
MADE IN BRAZIL
WEG, CP40 - 89256-900
Jaraguá do Sul - Brazil
17 N
7 909158 764266
CFW-11 RB model
WEG part number
Rated input data (voltage,
number of power phases,
rated currents for use with
Normal Duty (ND) and Heavy
Duty (HD) cycles, frequency)
Current specifications for use
with the Normal Duty (ND) cycle
Current specifications for
use with the Heavy Duty (HD)
cycle
Maximum surrounding air
temperature
Serial number
Manufacturing date (17 corresponds
to the week and N to the year)
Rated output data (voltage, number
of power phases, rated currents
for use with Normal Duty (ND) and
Heavy Duty (HD) cycles, overload
currents for 1min and 3 s, and
frequency range)
1.42 X LINE - DC
691 A
592 A
-Hz
A (ND)
60s / 3s
A (HD)
60s / 3s
AC TERMINALS
BORNES CA
380 - 480 V
601 A
660 A / 900 A
515 A
773 A / 1030 A
50 - 60 Hz
(a) Nameplate affixed at the side of the converter
EUCFW110 601T40R BZ
12784255
SERIAL#:
17 N
Manufacturing date
(17 corresponds to
week and N to year)
CFW-11 RB model
WEG part number
Serial number
(b) Label located under the keypad
Figure 2.7: (a) and (b) - Identification labels for 220...230 V and 380...480 V models

WEG CFW-11 RB Specifications

General

Brand	WEG
Model	CFW-11 RB
Category	Media Converter
Language	English
