General Information
2-12 | CFW-11 RB
2.5 CFW-11 RB MODEL SPECIFICATION (SMART CODE)
In order to specify the CFW-11 RB, it is necessary to fill in the desired voltage and current values in the respective
fields for the nominal supply voltage and the rated input current for normal duty (ND) cycle in the smart code
according to the example on Table 2.1 on page 2-12.
Table 2.1: Smart code
Converter Model Available Option Kits
Refer to Chapter 8 TECHNICAL SPECIFICATIONS on page 8-1 for the CFW-11 RB list of models and for the complete technical specifications
Refer to the Chapter 7 OPTION KITS AND ACCESSORIES on page 7-1 for more details on the options
Example BR CFW11 0370 T 4 O RB _ _ _ _ _ _ Z
Field description
Market identification (defines the manual language and the factory settings)
WEG 11 frequency converter series
Rated current for Normal Duty (ND) cycle
Number of power phases
Power supply voltage
Option kit Braking
External 24 Vdc control power supply
Special hardware
Special software
Character that identifies the end of the code
Available options
2 characteres Possible
options presented in Table 2.2 on page 2-13
T = threephase
2 = 220...230 V 4 = 380...480 V 6 = 660...690 V
O = product with option kit
RB = Regenerative Braking
Blank = standard (not available) W = with external 24 Vdc control power supply
Blank = standard H1= special hardware n°1
Blank = standard S1 = special software n°1
