General Information
CFW-11 RB | 2-11
MOD.: SACFW110170T60RBZ
MAT.: 12551189
OP.: 8888888888
PESO/WEIGHT: 115 kg (253 lb)
SERIAL#.: 8888888888
MAX. TA: 45 °C (113 °F)
LINE
LINEA
REDE
OUTPUT
SALIDA
SAÍDA
LINE
LINEA
REDE
OUTPUT
SALIDA
SAÍDA
500...600
3~ VAC
660...690
3~ VAC
0-REDE
3~
0-REDE
3~
147 A170 A 170 A
187 A
255 A
147 A
162 A
221 A
150 A
225 A
300 A
150 A
127 A
191 A
254 A
127 A
VAC
A (ND)
60 s
3 s
A (HD)
60 s
3 s
Hz 50/60 Hz 50/60 Hz0 - 300 Hz 0 - 300 Hz
FABRICADO NO BRASIL
HECHO EN BRASIL
MADE IN BRAZIL
WEG, CP40 - 89256-900
Jaraguá do Sul - Brazil
17 N
7 909158 266388
CFW-11 RB model
WEG part number
Rated input data (voltage,
number of phases, rated
currents for operation with
ND and HD overload cycles,
frequency)
Current specifications
for operation with normal
overload cycle (ND)
Current specifications
for operation with heavy
overload cycle (HD)
Maximum surrounding air
temperature
Serial number
Manufacturing date (17
corresponds to the week and
N to the year)
Rated output data (voltage,
number of phases, rated
currents for operation with
ND and HD overload cycles,
overload currents for 1 min
and 3 s, frequency range)
(a) Nameplate affixed to the side of the converter
SACF W110170T6 0RBZ
12551189
SERIAL#:
17 N
Manufacturing date
(17 corresponds to
week and N to year)
CFW-11 RB model
WEG part number
Serial number
(b) Nameplate located under the keypad
Figure 2.8: (a) and (b) - Identification labels for 500...690 V models
