WEG CFW-11 RB - Page 85

8
Technical Specifications
CFW-11 RB | 8-9
8
Frame Size F
430 [16.93]
213
[8.39]
24 [0.94]
313 [12.33]
1234 [48.57]
24 [0.94]
338 [13.29]
1156 [45.51]
572 [22.52]
290 [11.43]
192
[7.56]
88 [3.46]
Ø29 [1.12] (4x)
Ø28
[1.11]
360,5 [14.19]
169
[6.67]
191
[7.52]
39 [1.53]
R6 [0.22]
19 [0.75]
16 [0.63]
15 [0.59]
38 [1.50]
R6 [0.22]
R10 [0,39]
150
[5.91]
150
[5.91]
M10 (6x)
A
A
B
B
150
[5.91]
150
[5.91]
1200 [47.2 9]
M12 (4x)
66 [2.60]
30 [1.18]
60 [2.36]
205 [8.07]
40 [1.57]
338 [15.28]
287 [11.29]
Figure 8.3: Frame size F dimensions - mm [in]
