WEG CFW-11 RB - Page 86

8
Technical Specifications
8-10 | CFW-11 RB
8
Frame Size G
A
B
B
A
15 [0.59]
40 [1.57]
16 [0.63]
41 [1.61]
426 [16.76]
224 [8.83]20 2 [ 7.9 4]
163 [6.42]163 [6.42]
Ø38 [1.50]
Ø11 [0.44]
Ø20 [0.79]
Ø28,5 [1.12](4x)
25 [0.99]
20 0 [7.87 ] 20 0 [7.87 ]
20 0 [7.87 ]
1224 [48.20]
20 0 [7.87 ]
R6 [0.22]
M10(6X)
492 [19.37]
422 [17.42]
317 [12.47]
590 [23.21]
313 [12.32]
213 [8.39]
1190 [46.85]
325 [13.87]
103 [4.06]
25 [0.97]25 [0.97]
535 [21.04]
73 [2.95]
26 [1.02]
26 [1.02]
60 [2.36]
62 [2.44]
M12(4x)
273 [10.74]
1264 [49.78]
Figure 8.4: Frame size G dimensions - mm [in]
