2
General Information
2-2 | CFW-11 RB
USB: Universal Serial Bus; is a serial bus standard that allows devices to be connected using the ”Plug and Play”
concept.
PE: Protective Earth.
RFI Filter: Radio-Frequency Interference Filter for interference reduction in the Radio-Frequency range.
PWM: Pulse Width Modulation; pulsed voltage at the input of the regenerative converter.
Switching Frequency: frequency of the IGBTs switching, normally expressed in kHz.
General Enable: when activated, the converter controls the voltage at the DC Link. When deactivated, this
function immediately blocks the PWM pulses. The General Enable function may be controlled through a digital
input set to this function.
Heatsink: metal device designed to dissipate the heat generated by the power semiconductors.
Amp, A: ampères.
°C: celsius degree.
°F: Fahrenheit degree.
AC: alternated current.
DC: direct current.
CFM: Cubic Feet per Minute; unit of flow.
cm: centimeter.
ft: foot.
hp: horse power = 746 Watts; unit of power, used to indicate the mechanical power of electrical motors.
Hz: hertz.
in: inch.
kg: kilogram = 1000 grams.
kHz: kilohertz = 1000 Hertz.
l/s: liters per second.
lb: pound.
m: meter.
mA: miliampère = 0.001 Ampère.
min: minute.
mm: millimeter.
ms: millisecond = 0.001 seconds.
N.m.: newton meter; unit of torque.
rms: root mean square; effective value.
