WEG CFW08 Vector inverter User Manual

26
GENERAL INFORMATION
CFW-08 0040 B 2024 P O 00 00 00 00 00 00 Z
Rated Output Current for 200 to 240V: 0016=1.6A 0026=2.6A 0040=4.0A 0070=7.0A 0073=7.3A 0100=10A 0160=16A 380 to 480V: 0010=1.0A 0016=1.6A 0026=2.6A 0027=2.7A 0040=4.0A 0043=4.3A 0065=6.5A 0100=10A 0130=13A 0160=16A
Number of phases of the power supply: S=single phase T=three phase B=single phase or three phase
Manual Language: P= Portug. E= English S= Spanish F= French G= German
Power Supply: 2024 = 200 to 240V 3848 = 380 to 480V
Options: S= standard O= with optiions
Degree of Protection: Blank = standard N1= Nema 1
Human Machine Interface: blank standard SI= without interface (with dummy panel)
WEG Series 08 Frequency Inverter
Control Board: Blank = standard control A1= control 1 (Plus Version)
Special Software: 00 = none
End Code
RFI Filter: Blank= without filter FA= Class A RFI filter (internal or footprint)
Special Hardware: 00 = none
HOW TO SPECIFY THE CFW-08 MODEL:

WEG CFW08 Vector inverter Specifications

General

Frequency Range	0 to 300 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Communication	RS485, Modbus RTU
Voltage	200 V to 240 V
Control Mode	Vector Control
Ambient Temperature	-10°C to 50°C
Input Frequency	50 Hz / 60 Hz
Output Voltage	0 to input voltage
Braking	Dynamic braking resistor (optional)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Operating Temperature	-10°C to 50°C
Cooling Method	Forced air cooling (fan)
Humidity	5% to 90% non-condensing
