Connectors
PLC300 | 3-3
XC3 – Encoder input, RS-232 and RS-485
Table 3.3: Function of the pins of the encoder, RS-232 and RS-485 input
Pino Função
1 A - encoder A signal.
2
A - encoder A signal.
3 B - encoder B signal.
4
B
- encoder
B
signal.
5 Z - encoder Z signal.
6
Z - encoder Z signal.
7 +5/12 Vdc - encoder supply.
8 0 V – encoder supply.
9 RS-232 rate.
10 RS-232 RX.
11 RS-232 GND.
12 RS-485 signal A (-).
13 RS-485 signal B (+).
14 RS-485 GND (insulated).
XC6 – CAN
Table 3.4: Function of the pins of the XC6 - CAN
Pin Function
1 V -
2 CANL
3 SHIELD
4 CANH
5 V + (11 to 30 Vdc)
XC8 – Power Supply
Table 3.5: Function of the pins of the XC8 - Power Supply
Pin Function
1 V+ (20 to 28 Vdc)
2 GND
3 Ground
XC4 – Ethernet
Ethernet standard connector.
