Dimensions
PLC300 | 16-3
16.1 MECHANICAL MOUNTING
Mounting on Panel (DIN rail or screw)
Figure 16.2: Mounting on panel
Mounting on the Panel Door
Note: dimensions of the slot for mounting on the panel door: 189 x 152 mm
Figure 16.3: Mounting on the panel door
