Dimensions
16-2 | PLC300
187.13 ( 7. 37)
52.53
(2.06)
150.13 (5.91)
174.65 (6.87)
Ø 4.8 (0.19)
178.97 (7.09)
166.17 (6.54)
Figure 16.1: Dimensions of the PLC300
