Configuration of the PLC300
7-4 | PLC300
RS232 Setup
--------------------
>Baud Rate:9600bps
Parity:NO
Stop Bits:1sb
The arrows <> and <> select the option to be changed. By pressing <ENTER>, the
cursor flashes in the operating mode to be changed.
The arrows <> and <> browse through the possible values:
Baud rate: 1200, 2400, 4800, 9600,19200, 38400 or 57600 bps.
Parity: NO,ODD,E V E N.
Stop bits: 1 or 2sb.
<ENTER> accepts the changed value. <ESC> aborts.
<ESC> returns to the main menu of the setup.
7.9 RS-485 SETUP
It is possible to configure the baud rate, the parity and the number of stop bits, the mode
(master/slave/telegram
1
) and the address of the PLC300 in a Modbus RTU network by
means of the RS-485 serial interface.
RS485 Setup
--------------------
>Baud Rate:19200bps
Parity :NO
Stop Bits:1sb
Mode :Master
Address :001
The arrows <> and <> select the option to be changed. By pressing <ENTER>, the
cursor flashes in the operating mode to be changed.
The arrows <> and <> browse through the possible values:
Baud rate: 1200, 2400, 4800, 9600, 19200, 38400 or 57600bps.
Parity: NO,ODD,E V E N.
Stop bits: 1 or 2sb.
Mode: Master, Slave or Telegram.
(1) There are two modes reserved for future aplications.
