Configuration of the PLC300
7-6 | PLC300
The arrows <> and <> select the option to be changed. By pressing <ENTER>, the
cursor flashes in the operating mode to be changed.
In the editing of the IP address, subnet mask and default gateway, the number can be
typed directly by the numeric keyboard. The <DEL> key deletes the last digit.
IP Address: 4 bytes of address that identify the PLC300 in the IP network;
Subnet: 4 bytes that identify the subnet to which the PLC300 belongs in the IP network;
Gateway: 4 address bytes that identify the default gateway to access other subnets in the
IP network;
The arrows <> and <> browse through the possible values:
DHCP: Disabled, Enabled.
Speed/Duplex: Auto, 10MBps Full Duplex, 10MBps Half Duplex, 100MBps
Full Duplex, 100MBps Half Duplex.
<ENTER> accepts the changed value. <ESC> aborts.
<ESC> returns to the main menu of the setup.
7.12 MB TCP SETUP
It is possible to configure the TCP port, Unit ID, IP authentication and timeout of the Gateway
Modbus TCP/RTU of the PLC300 in an Ethernet network by using the Modbus TCP protocol.
MB TCP Configuration
--------------------
>TCP Port:
00502
Unit ID:
255
IP authentication:
000.000.000.000
GW Timeout
0100
The arrows <> and <> select the option to be changed. By pressing <ENTER>, the
cursor flashes in the operating mode to be changed.
The arrows <> and <> browse through the possible values:
TCP Port: 0 to 65535.
Unit ID: 1 to 255.
Gateway Timeout: 20 to 5000 ms.
