WEILER E1250
3-6
Maintenance
3
CONVEYOR CHAIN
1. Open conveyor clean out door, as described in the following
steps.
a. Lower the conveyor to allow the cleanout door
skid tubes (1) to be lowered to the down position.
b. Lower the conveyor skid to the bottom set of holes
(2) and place pin (3) in each side.
c. Lower the conveyor until skid tubes rest on the
ground.
d. Release cleanout door latches (4).
e. Raise the conveyor until the cleanout door exposes
the conveyor chain.
