2-7
Operation
2
WEILER E1250
CLEANING STALLED MACHINE
DANGER: NEVER USE TOOLS TO REMOVE MATERIAL FROM A STALLED MACHINE WITH THE
ENGINE RUNNING. PERSONAL INJURY OR DEATH MAY RESULT.
CAUTION: Asphalt is hot and will burn skin. Use caution when opening doors to not allow the asphalt to
contact the skin.
UNLOADING ELEVATOR
In the event of a stalled unloading elevator use the following steps to remove material to free the slats.
1. Run the elevator in reverse to remove material from the chute of the machine. If the hopper is loaded, it may be
necessary to open the hopper clean out door to allow material to discharge from the chute onto the ground. If this
does not free the elevator proceede to step 2.
2. Open the drop out floor using the following steps:
a. If hopper clean out door is still open, close it or
damage to the door may result. Lower elevator to
ground (until stops (1) hit frame tube).
b. Loosen clean out latches (2).
c. Raise elevator to open door (3).
3. Run the elevator in reverse to remove material from the chute
of the machine. The material will discharge down the drop out
floor and onto the ground.
4. Shut off the engine and clean the material off of the drop out
door to allow it to shut tightly. Be certain to get all material
cleaned off of the sealing edges or the door will not fully shut.
5. Start engine and close clean out door, as described in the
following steps.
a. Lower elevator to the ground (until elevator forces door to close), verify that there is not material
keeping the door from closing, if so clean material out and reclose the door.
b. Lock the door with the latches.
6. Clean material off of the paving surface with a loader or other machine and proceed with the paving operation.
