Safety instructions 13
EN
Rear
16
Unit inlet: inlet for ambient air at room temperature
33
Servicing label: indicates when the next service is due.
34
Safety check label: (in Germany only) marks when the next safety check as per §6
of the German law relating to users of medical devices is required.
Side connection sockets
4a Connection for specialist staff to adjust therapy parameters with VENTIsupport,
WM 93340; max. power consumption at 12 V: 15 mA
4b Connection for optional additional SaO
2
devices; max. power consumption at 12
V: 25 mA
19 Connection for supply-independent operation using VENTIpower, WM 24100;
power supply: 12 V/40 V DC
20 Connection for controlling the O
2
connection valve VENTI-O
2
, WM 24200.
Max. power consumption at 12 V: 125 mA
Rating plate
Do not dispose of the unit in domestic waste!
Protection class B
Protection class II, protective insulation
Year of manufacture
