Westen Pulsar E - Page 171

171
S E C T I O N D
7113126.02 (3-08/13)
A B
Lmax = 5 m - Ø 60/100 mm
C D
Lmax = 4 m - Ø 60/100 mm
E
Lmax = 5 m - Ø 60/100 mm
F G
Lmax = 4 m - Ø 60/100 mm
H
Lmax = 2 m - Ø 60/100 mm
I
Lmax = 3 m - Ø 60/100 mm
L
L2 max = 22 m - Ø 80 mm
L1 max = 8 m - Ø 80 mm
M
L max = 8 m - Ø 80 mm
N
L max = 7 m - Ø 80 mm
L2
L1
L
L
CG_2130
L
M
N
CG_1641
L
L
L
L
F G H I
L
L
E
CG_1640
L
L
L
L
A
B
C
D
CG_1639
E
