Westen Pulsar E - PARAMETER SETTINGS; EDITING BOILER PARAMETERS

37
I N S TA L L E R S e c t i o n ( e n )
7113126.02 (3-08/13)
14. PARAMETER SETTINGS
To set the boiler parameters, press and together and hold down for at least 6 seconds. When the function is activated, the
display shows “F01” alternated with the value of the parameter.
Edit parameters
• To scroll the parameters press ;
• Press buttons to change the single parameter value;
• Press to save changes, the display shows “MEM”;
• Press to leave the function without saving, the display shows "ESC".
ALL MODIFIED PARAMETERS SHOULD BE NOTED DOWN IN THE TABLE AT THE END OF THIS MANUAL.
Parameter Description of parameters
Factory settings
24 F 1.24 F
F01 Boiler type 010=airtight chamber 010
F02 Gas used 000=NATURAL GAS - 001=LPG - 002=gas G25.1 000 - 001
F03
Hydraulic system
000 = instantaneous appliance
003 = appliance with external storage boiler
004 = heating only appliance
000 004
F04 - F05
Setting programmable relays 1 and 2 (See SERVICE instructions)
000=no associated function
000
F06
Maximum heating setpoint setting (°C)
000=85°C (Burner goes out at 90 °C)
001=45°C (Burner goes out at 50 °C)
000
F07 DHW inlet priority conguration 000
F08 CH max. output (0-100%) 55 (60 LPG) 100
F09 DHW max. output (0-100%) 100
F10 CH and DHW min. heat output (0-100%) 000
F11
Delay prior to new ignition in CH mode
000=10 seconds - 001...010 = 1...10 minutes
003
F12 Identication of boiler model 007
F13
Pump overrun time in heating mode
000=10 seconds - 001...240 = 1...240 minutes
003
F14
Test of correct DHW probe position 000=Disabled - 001=Always
enabled
000
F15 Factory setting 000
F16
Anti-legionellosis function
000 = Disabled - 055…067 = Enabled (setpoint 55…67°C)
000
F17 Hydraulic pressure switch conguration 001
F18 Release parameters for SERVICE 000
Parameter Description of parameters
Factory settings
Parameter Description of
parameters
Factory settings
24 F - 1.24 F 24 F - 1.24 F
F19 Factory setting 001 F44 Factory setting 000
F20 Factory setting 000
F45 Factory setting
(this value depends on
valve calibration)
F21 Factory setting 030
F22 Factory setting 110 F46 Factory setting 015
F23 Factory setting 010 F47 Factory setting 000
F24 Factory setting 005
F48 Factory setting
(this value depends on
valve calibration)
F25 Factory setting 000
F26 Factory setting 165 F49 Factory setting 105
F27 Factory setting 010 F50 Factory setting 100
F28 Factory setting 070 F51 Factory setting 005
F29 Factory setting 020 F52 Factory setting 020
F30 Factory setting 000 F53 Factory setting 100
F31 Factory setting 180 F54 Factory setting 000
F32 Factory setting 170 F55 Factory setting 003
F33 - F34 Factory setting 004 F56 Factory setting 025
F35 Factory setting 015 F57 Factory setting 000
F36 Factory setting 020 F58 Factory setting 000
F37 Factory setting 003 F59 Factory setting 005
