INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 3-40 SECTION 3: INSTALLATION & ADJUSTMENTS
Channel Pairs
A1
TX 2410
RX 2451
A2
RX 2410
TX 2451
B1
TX 2424
RX 2465
B2
RX 2424
TX 2465
Figure 3Figure 3-- 3: Channel Plan, 2.4 GHz 4xE13: Channel Plan, 2.4 GHz 4xE1
Figure 3Figure 3-- 4: Channel Plan, 5.8 GHz 1xE1, 4xE14: Channel Plan, 5.8 GHz 1xE1, 4xE1
A1 B1 B2
A2
