INSTALLATION AND MAINTENANCE MANUAL
E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
SECTION 2: PRODUCT DESCRIPTION PAGE 3-41
Figure 3Figure 3-- 5: Channel Plan, 5.8 GHz 2xE15: Channel Plan, 5.8 GHz 2xE1
A1 A2
Channel Plan
A1 A2
Tx: 5750 MHz Rx: 5750 MHz
Rx: 5825 MHz Tx: 5825 MHz
Figure 3Figure 3-- 6: Channel Plan, 5.8 GHz 8xE16: Channel Plan, 5.8 GHz 8xE1
GRAPHICAL FREQUENCY PLAN FOR 1.5 GHZ – TO BE SUPPLIED
(refer to Section 2.2.4)
