INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 3-64 SECTION 3: INSTALLATION & ADJUSTMENTS
Figure 3Figure 3-- 16: Typical RF Output Power16: Typical RF Output Power ve versus PWR Voltage, 1.5 & 2.4 GHz rsus PWR Voltage, 1.5 & 2.4 GHz
ModelsModels
Use the Lynx Factory Test Data sheet to determine more
precisely the voltage corresponding to the RF output power.
