Westfield XTR2 - Page 32

4.5
Step 5: Main Loom Identifier & Installation
Near Side
Indicator
Front
Of Car
Rear
Of Car
Fuse Box
Brake Level warning Light
Brake Light Switch
Clutch Switch
Handbrake Warning Light
Horn
Nose Loom
Main Earth Lead
Main Loom Battery +ve supply
(Connects To Master Switch)
Earth For
Resistor
Circuit On
Master
Switch
A
uxiliary
Plug
Dash Loom
Connectors
Primary
Fuel Pump
Earth
To High
Pressure
Fuel Pump
Engine Loom
Off-Side Rear
Light Cluster
Fog Light
Number Plate Light
Near-Side Rear
Light Cluster
Cooling Fan
Motor
Coolin
g
Fan Switch
Fuel Tank Sender
