Symbol Name Explanation Photo
E
Control pad This is the round unit where
the various buttons are
located.
It can be used to control the
following functions.
1. Speaker
2. Display
3. Speed increase button
4. Speed decrease button
(decelerate)
5. Horn
6. Power button
F
Seat assembly
release lever
This lever is used to separate
the seat assembly from the
rear drive base.
G
Storage basket This basket is used to carry
storage items.
It is installed onto the front
drive base.
H
Rear wheel This is the device rear wheel.
3
4
5
6
2
1
