8. Disconnect the plug from the wall outlet and
disconnect the DC connector cord from the
battery.
9. Close the battery charging port cap.
10. Install the battery onto the device.
1) Grasp the battery handle and align the
battery with the projections on the bottom
of the mounting area.
The battery weighs 6.2 lbs (2.8 kg). Be careful
not to drop it when handling it. There is a risk
of injury, and of damage to the battery.
2) Press the top of the battery in to install it.
11. Turn the key counter-clockwise to lock the
battery, and then remove the key.
Projec-
tions
