WinGD X92-B - Lp Scr Page Index; Page - LP SCR

Fig 4-24 LDU-20 page - LP SCR PAGE INDEX
004
001 002 003
Tab 4-5 LP SCR PAGE INDEX
Item Function Effect
001 INDEX button Opens the index page
002 SCREENSHOT button Makes a screenshot of the current screen
003 RCS CTRL ON button Gets control from the remote control system (if button is active)
004 Page button Opens the selected page
X92-B
AA00-9270-00AAA-043B-A
Operation Manual LP Selective catalytic reduction system
Winterthur Gas & Diesel Ltd.
- 105 - Issue 002 2021-11
