WinGD X92-B - Control Air System (Generic and Simplified)

Fig 4-9 Control air system (generic and simplified)
40
PLANT ENGINE
E
45
A3
A1
A2
A6
A
PLANT ENGINE
007
006
005
001002003004
Cyl. 1 Cyl. n
Legend
001 Air bottle 005 Starting air shut-off valve
002 Control air supply 006 Valve unit for start
003 Air tank 007 Collector for leakage oil from the air spring
004 Disengaging device
X92-B
AA00-0000-00AAA-043T-A
Operation Manual Control air system
