Installation, Operating and Maintenance
Instructions blueMatic EAV
22
Aug. Winkhaus GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen www.winkhaus.de
Subject to technical changes
Sash part STV-KÜ-T1 FT 2 M
1)
5040501
Sash part STV-KÜ-T1 FT 3,5 M
2)
5040505
Sash part STV-KÜ-T1 SET FT INTEGR-EAV FT 1 M + KABEL 3 M
3)
5040511
Sash part STV-KÜ-T1 SET FT ZK-EAV FT 4 M + KA 3,5 M
4)
5040508
Sash part STV-KÜ-T1 SET FT ZK-SO + EAV FT 1 M + KABEL 3 M
5)
5040513
Frame part STV-KÜ-T1 RT KABEL 4 M 5040503
Frame part STV-KÜ-T1 RT KABEL 0,6 M RNT 5040504
STV-COVER PLATE KÜ-T1 FT F16 R8 MC (for sash)
6)
4990670
STV-COVER PLATE KÜ-T1 FT F20 R10 MC (for sash)
7)
4990671
STV-LF COVER PLATE KÜ-T1 FT F24 KANT MC (for sash)
8)
5018556
STV-LF COVER PLATE KÜ-T1 RT F24 X 350 MC (for frame)
9)
5028782
1)
for use with EAV (if applicable BM), sash part 2 m cable + plug for motor housing
2)
for use with EAV (if applicable BM), sash part 3.5 m cable + plug for motor housing
3)
for use with EAV and ngerprint ekey home integra, sash part with 1 m cable, end of
the cable with 8-pole plug (for control unit ekey home integra) + connecting cable
for motor 3-wire
4)
for use with EAV with sash side access control systems (eg. Fingerprint IDENCOM
BioKey INSIDE or ekey home SE micro), sash part with 3.5 m cable + 5-pole plug
for connection with Y-cable + Y-Kabel INSIDE EAV 0.5 m
5)
for use with EAV with Sommer ngerprint ENTRAsys FD, Set with sash part KÜ-T1-
SOMMER-EAV + connecting cable for motor SOMMER 3 m
6)
Cover plate for sash, at faceplate 16 mm, round ends R8, length 126 mm, suitable
for PVCu (timber if necessary)
7)
Cover plate for sash, at faceplate 20 mm, round ends R10, length 130 mm, suita-
ble for timber (PVCu if necessary)
8)
Cover plate for sash, at faceplate 24 mm, square, length 134 mm, suitable for ALU
(PVCu if necessary)
9)
Cover plate for frame, at faceplate 24 mm, angulate, square, length 350 mm, sui-
table for ALU (with tting groove 24 mm), suitable for example for heroal D92 UD
NOTICE!
If no separable cable transition (eg. STV-KÜ M1188) or no Winkhaus cable transition
is used, then the STV-cable 6 m for motor housing (2522881) must be used.
