SPL option
SPL option mounts an optical splitter inside MFL. It can be used when it is required to carry the same optical signal
to several remote zones. Different type of splitters are available [1:2], [1:3] or [1:4].
NOTE: Splitter module is NO BI-DIRECTIONAL, it can be used only if all the optical signals go on the same way.
Example of application: transmittion of 4 IEM channels on 2 remote areas
Double OMS option
A double OMS option can be installed on MFL. It can be usefulto receive 2 remote areas in a single MFL (as on the
below example). This configuration
reduces the number of the fiber cable
reduce the MFL in the LOCAL area
allows remote management of both the remote areas
Example of application: reception from 2 remote areas
