SYSTEM DESCRIPTION
MFL provides wideband optical link for up to 4 RF channels combined in one single mode fiber thanks to
CWDM technology. It is designed to allow for a flexible and modular configuration thanks to a mainboard
that can be fitted with up to 4 plug-in boards that can be chosen any combination of two types:
• TX: Laser optical transmitter, (CDWM) plug-in board
• RX: Optical-receiver plug-in board
To simplify the usage we give a name of the final configuration that easy identify the CWDM channels and
a color code for the RF connectors (N type). We use as default 4 laser wavelength although the CWDM
standard can allow to use much more with a 20nm wavelength separation:
 Channel 51 short name for wavelength 1510 nm
 Channel 53 short name for wavelength 1530 nm
 Channel 55 short name for wavelength 1550 nm
 Channel 57 short name for wavelength 1570 nm
Wavelength and Color Coding:
Example of some possible configurations:
- MFL-TTTT is a 4 laser transmitters on channel 51/53/55/57 (λ = 1510/1530/1550/1570 nm)
- MFL-RRTT has 2 receivers on ch. 51/53 and 2 transmitters ch. 55/57 (it works with MFL-TTRR)
- MFL-TTRR has 2 transmitters on ch51/53 and 2 receivers on ch. 55/57 (it works with MFL-RRTT)
- MFL-TT-- has 2 transmitters on ch51/53
Channel
Wavelength
Color
Identifier
51
Wavelength 1510 nm laser, single mode
Blue
53
Wavelength 1530 nm laser, single mode
Green
55
Wavelength 1550 nm laser, single mode
Yellow
57
Wavelength 1570 nm laser, single mode
Orange
NAME
Ch. 51
Ch. 53
Ch. 55
Ch. 57
MFL-TTTT
T
T
T
T
NAME
Ch. 51
Ch. 53
Ch. 55
Ch. 57
MFL-RRTT
R
R
T
T
NAME
Ch. 51
Ch. 53
Ch. 55
Ch. 57
MFL-TTRR
T
T
R
R
NAME
Ch. 51
Ch. 53
Ch. 55
Ch. 57
MFL-TT--
T
T
-
-
