WisyCom MFL - Menu Tree

MFL User Manual
22
MENU TREE
Main
Name
Optical connectors CONN# 1 / 2 / 3 / 4 / 5
DISPLAY brightness 1÷15
DISPLAY timeout 5÷120
Info
IP Address
Serial
FW
FW ver
Boot ver
App FW ver
Temperatures
Main Board
Temperature of the
TX
Supply diagnostic
Supply source
External DC
Main RAW (+12v6)
Main Digital (+5v)
Main Analog (+5v)
Laser supply (-5v)
Alarms
History alarm list
Current alarm list
Date/time
Life time
Ext. DC alarm
threshold
OFF / 10.0÷28.0 V
High opt. power
alarm
disabled / enabled
Preset
FACTORY / PRESET 1 / ... / PRESET 10
Opt. loss
calibration
Optical loss measure RXs
