Only with ANT Mode & BPF filter.
BPF settable only with the option
BF1/F41/F42/F45
TX LINK Menu
Status ON/OFF
Mode
IFB / ANT / 1ifb / 2ifb / 3ifb / 4ifb
Filter 150-960* / 470-960* / BPF / EXTERN
BP filter
BF1 filter Tunable filter freq. 404÷788 MHz (Bandwidth 25MHz)
F41 filter
Tunable filter 410-730MHz, 40MHz of Bandwidth
Selectable Filter HP: 410/470/510 MHz + LP: 600/700/810 MHz
Fixed Filter 940 ÷ 960 MHz (Europe/Usa)
F42 filter
Tunable filter 410-730MHz, 40MHz of Bandwidth
Selectable Filter HP: 470/520/550 MHz + LP: 617/662/698 MHz
Fixed Filter 940 ÷ 960 MHz (Europe/Usa)
F45 filter
Tunable filter 410-730MHz, 40MHz of Bandwidth
Selectable Filter HP: 410/470/510 MHz + LP: 600/714/810 MHz
Fixed Filter 806 ÷ 810MHz (for Japan)
Gain
With IFB Mode: -23.5 ÷ 8.0 dB
With ANT Mode & filter
150-960: -20.0 ÷ 11.5 dB
470-960: -20.0 ÷ 11.5 dB
BPF -28.0 ÷ 3.5 dB
EXTERN: -22.0 ÷ 9.5 dB
Booster
enabled / disabled
Booster supply
12 Vdc xx mA
Failsafe enabled / disabled
Ext filter att. 0.0 ÷ 6.0 dB
BP filter
ID
Serial
App FW ver
Center freq range
Filter bandwidth
Transmitter
param
ID
Serial
TX laser current
Current limits
Optical power
Temperature
Offset gain
Wavelength
Life time
*150-840/470-840 for hardware revision < 21
