7 Layout
1 Cylinder heating from above with deector and divider
2 DHW draw-off at the highest point
3 Cold water supply with control and distribution appliance
4 Cold water draw-off for cylinder heating
5 DHW circulation line
6 Protective magnesium anode
7 Sensor well for cylinder temperature sensor
8 Drain (in standard delivery)
9 Trap
10 Neutralising system (accessory)
11 Condensate pump (accessory)
COB-TSoilcondensingboilerwithstraticationcylinder
Cold water
DHW
DHW circulation
Oilcondensingboiler
Straticationcylinder
TSstraticationcylindercannotbeinstalledwithCOB-40
