9 Sitinginstructions
Transport
Boiler/straticationcylinder
- The boiler and the stratication cylinder are transported, fully packaged, on a pallet
- A sack truck is a suitable means of transportation
- Position the sack truck behind the boiler or stratication cylinder, secure with a strap
and transport to the installation location
- Remove strap and packaging
- Remove the two xing screws on the pallet
- Lift the boiler and/or stratication cylinder off the pallet
The COB and TS are installed adjacent to the wall, which means that a clearance of
70 cm only needs to be observed at the front. When installing the boiler, you should
observe the recommended wall clearances in order to simplify installation, maintenance
and servicing. The COB-40 requires a minimum room height of 1.90 m.
The minimum clearance via COB-15/20/29 is 30 cm, for the COB-40 this is 40 cm.
Recommended minimum
wallclearances
COB with
TS (right
or left)
COB-40
minimum
room height
COB
COB with
CS behind
70 cm
70 cm
70 cm
70 cm
70 cm70 cm
190 cm
Installationinformation
Adjustable feet
- Alevelandload-bearingbaseisrequiredfortheinstallationofthe
boileror thestraticationcylinder, toprevent air collectionin the
boilerandthereforesystemfaults.
- Levelthe boiler and stratification cylinder horizontally using
adjustablefeet.
- Openueoilcondensingboilersmustonlybeinstalledinaroom
which complies with the appropriate ventilation requirements.
Otherwise there is a risk of asphyxiation or poisoning from the
escapinguegas,causedbyoperationwithaleakinguegassystem.
- Theboilermayonlybeinstalledinafrost-freeroomtopreventthe
frostdamagingtheinstallation.Draintheboiler,straticationcylinder
andheatingsystemifthereisariskoffrostwhenthesystemhas
beenshutdown.
- The boiler may not be installed in a room with corrosivevapours
orinverydustyconditions(workshops,washrooms,hobbyrooms
etc.),sincethismayleadtodamagetothecomponentsand/orheavy
contaminationoftheheatexchanger.
- Thecombustionairmustbefreefromhalogenatedhydrocarbons.
Halogenated hydrocarbons lead to premature aging of the heat
exchanger,duetocorrosion.
With the COB, a surface temperature of 40°C is not exceeded during proper use. For
installation in oil storage rooms, the respective state re regulation must be adhered to.
Note
Note
Note
Note
