Manual 26815 QuickTrip Electro-Hydraulic Trip Block Assembly
Woodward 7
EAC Customs Union
Declared to Technical Regulation CU 020/2011 On Electromagnetic
Compatibility of Technical Equipment Declaration of Conformity
Registration No: RU Д-US.AЛ32.B.05234
Item Prefix(es): 3, 4
Other International Compliance
These listings are limited only to those units bearing the appropriate agency certification marking.
IECEx:
Certified for use in explosive atmospheres per Certificate:
IECEx CSA 15.0009X
Item Prefix(es): 1, 3 - Ex db IIB T4 Gb
Item Prefix(es): 1, 2, 3, 4 - Ex nA IIC T4 Gc
North American
Compliance
:
These listings are limited only to those units bearing the CSA identification
CSA:
(Item Prefix: 1)
CSA Certified For Class I, Division 1, Groups C & D, Class I, Division 2,
Groups A, B, C, & D, T4 at 85 °C Ambient. For use in Canada and the
United States. Certificate 2757391
CSA:
(Item Prefix: 2)
CSA Certified For Class I, Division 2, Groups A, B, C, & D, T4 at 85 °C
Ambient. For use in Canada and the United States. Certificate 2757391
SIL Compliance:
SIL
-
3:
Product has been evaluated to IEC 61508 Parts 1-2 and 4-7:2010 as well
as IEC 61511 Parts 1-3:2004 (in extracts) and has been found to be
suitable for use in a safety instrumented system up to SIL-3. The
instructions of the associated installation and Operating Manual shall be
considered and followed – reference “Safety Management” in Chapter 6
of this manual. See end of this manual for certificate and test results.
Certificate V 486.01./15
Special Conditions for Safe Use
Field wiring must be suitable for at least +85 °C and 10 °C above the maximum fluid and ambient
temperatures.
The maximum hydraulic fluid temperature shall not exceed 70°C.
Conduit stops must be installed within 45cm (18 inches) of the QuickTrip product in order to meet the
Zone 1 classification.
The following have a maximum constructional gap (ic) less than that required by Table 2 of EN 60079-1
and hence are as detailed below:
Flamepath Max Gap, ic (mm) Min. width of joint L (mm)
Sleeve to Spacer 0.08 12.852
Rotor to Spacer 0.08 13.46
Sleeve to Carrier 0.0483 14.757
Sleeve to Housing 0.178 14.097
Under certain extreme circumstances, the non-metallic parts incorporated in the enclosure of this
equipment may generate an ignition-capable level of electrostatic charge. Therefore the equipment shall
not be installed in a location where the external conditions are conducive to the build-up of electrostatic
charge on such surfaces. In addition, the equipment shall only be cleaned with a damp cloth.
Released
