Manual 26815 QuickTrip Electro-Hydraulic Trip Block Assembly
Woodward 23
Chapter 3.
Installation
Receiving Instructions
The QuickTrip is carefully packed at the factory to protect it from damage during shipping; however,
careless handling during shipment can result in damage. If any damage to the QuickTrip is discovered,
immediately notify both the shipping agent and Woodward.
Unpacking Instructions
Carefully unpack the QuickTrip and remove it from the shipping container. Do not remove the hydraulic or
electric blanking covers until the unit is ready for mounting.
The external ground lug shown on the installation drawing must be
properly connected to ensure equipotential bonding. This will reduce
the risk of electrostatic discharge in an explosive atmosphere.
External fire protection is not provided in the scope of this product. It
is the responsibility of the user to satisfy any applicable requirements
for their system.
Take care not to damage the electronics covers’ seals, the covers’
surface, threads, or the QuickTrip housing mating surface while
removing or replacing the covers.
For Zone 1/2 products: Proper torque on all joints is required to
ensure that the unit is sealed properly.
For lifting and transportation, use lifting straps fitted
lifting points on the product. Support the QuickTrip in a vertical
position during transportation.
Due to typical noise levels in engine and turbine environments,
hearing protection should be worn when working on or around the
QuickTrip.
The surface of this product can become hot enough or cold enough to
be a hazard. Use protective gear for product handling in these
circumstances. Temperature ratings are included in the specification
section of this manual.
