1. Descriptionofdevice
1.1 Overview-g.I
1. 16-pinOBD-IIconnector(SAE J1962) with integrated lighting
2. Multi-colouredLEDstatusdisplay showing connection status.
3. Button Flightrecorderbuttonforstarting/stoppingandsettingtriggersduringightrecorderoperation
4. USB-C port
5. LED lamp button in the extension cable
6. LED lamp button
7. Extension cable OBD-II connector
1.2 Descriptionofapplication-g.II
1. Removable hook clip with suction cup
2. Hook clip for attaching the LOOQER
1.3 Deviceinformation
Designation: LOOQER
Art. no.: W072 003 000
Display Opticalandacousticfeedbackoftherunningprocessesvia360°LEDlight
ring for an optimum diagnostic procedure
Warning sound if Bluetooth
®
/ WLAN connection is interrupted
Interfaces / Connections Bluetooth
®
v4.2 - BR/EDR and Bluetooth
®
Low Energy
(Class 2): Inner, protected Bluetooth
®
antenna, range up to 30 m
USB-C cable
Detachable extension cable with light
WLAN: 2.4 GHZ, 802.11b/g/n, range up to 400 m
Diagnostic connection: ISO 15031-3 (SAE J1962); 16-pin connector with
integrated LED light
Connectionofolderadaptercable(vehicle-specic)at16-pinOBDconnector
Replaceable OBD connector head
Power supply 6-36 V, protected against polarity reversal, max. current consumption 500 mA
Display of voltage monitoring of the vehicle battery on the unit and in the
diagnosis mask
Conformity RED 2014/53/EU, LVD 2014/35/EU, RoHs 2011/65/EU
Supported buses 2 x HS CAN (ISO 11898-2), SW CAN (SAE J2411)
K/L (ISO 9141-2), VPW (J1850), PWM (J1850), RS485 (J1708)
TTL and SPI, (analogue in, 5 volts out)
CAN-FD technology 3 CAN lines simultaneously – for fast CAN bus communication
DoIP – Diagnostics over Internet
Protocol
Integrated (ISO 13400-2)
Pass Thru J2534 Supports several channels – Pin button for one-channel support:
CAN, SW_CAN, ISO15765, SW_ISO15765, ISO9141, ISO14230
