wsm m9540 - Servicing Specifications

L3-S1
M9540Low Profile, WSM
TRANSMISSION
1. SERVICING SPECIFICATIONS
Main Shift Rod
W1013874
4WD/Bi-Speed Turn System
W1013874
Item Factory Specification Allowable Limit
Main Shift Rod 1
Main Shift Rod 2
Length
Length
322 mm
12.7 in.
178 mm
7.008 in.
–
–
Hydraulic System Pressure for Shuttle and
2WD-4WD-Bi-speed Turn
Pressure 2.06 to 2.15 MPa
21.0 to 22.0 kgf/cm
2
299 to 312 psi
–
Clutch Disc
(Both 4WD Side and Bi-speed Turn Side)
Thickness 2.1 to 2.3 mm
0.083 to 0.090 in.
1.9 mm
0.090 in.
Steel Plate
(Both 4WD Side and Bi-speed Turn Side)
Thickness 1.67 to 1.83 mm
0.0658 to 0.0720 in.
1.3 mm
0.051 in.
Pressure Plate
(Both 4WD Side and Bi-speed Turn Side)
Thickness 4.42 to 4.58 mm
0.174 to 0.180 in.
3.7 mm
0.15 in.
Piston
(Both 4WD Side and Bi-speed Turn Side)
Flatness – 0.15 mm
0.006 in.
Steel Plate
(Both 4WD Side and Bi-speed Turn Side)
Flatness – 0.40 mm
0.016 in.
Pressure Plate
(Both 4WD Side and Bi-speed Turn Side)
Flatness – 0.30 mm
0.012 in.
Seal Ring Thickness 2.39 to 2.44 mm
0.0941 to 0.0960 in.
2.0 mm
0.079 in.
KiSC issued 09, 2008 A
