L9-M5
M9540Low Profile, WSM
ELECTRICAL SYSTEM
[4] WIRING COLOR
W1019456
B ........... Black Br/B ........ Brown / Black Lg/Y ......... Light Green / Yellow
G .......... Green Br/Y ........ Brown / Yellow Or/W ......... Orange / White
L ........... Blue Br/R ........ Brown / Red P/W ............ Pink / White
P ........... Pink Br/W ........ Brown / White P/L .............. Pink / Blue
R ........... Red G/B ......... Green / Black R/B ............ Red / Black
V ........... Violet G/L ......... Green / Blue R/G ............ Red / Green
W .......... White G/Or ......... Green / Orange R/L ............. Red / Blue
Y .......... Yellow G/R ......... Green / Red R/W ............ Red / White
Br .......... Brown G/W ........ Green / White R/Y ............. Red / Yellow
GY .......... Gray G/Y ......... Green / Yellow V/W ............ Violet / White
Lg .......... Light Green L/B .......... Blue / Black W/B ............ White / Black
Or .......... Orange L/G .......... Blue / Green W/G ........... White / Green
Sb ......... Sky Blue L/Or ......... Blue / Orange W/L ............ White / Blue
B/G ......... Black / Green L/R .......... Blue / Red W/R ........... White / Red
B/L .......... Black / Blue L/W ......... Blue / White W/Y ........... White / Yellow
B/P .......... Black / Pink L/Y .......... Blue / Yellow Y/B ............ Yellow / Black
B/Pu ........ Black / Violet Lg/B ........ Light Green / Blue Y/G ............ Yellow / Green
B/R .......... Black / Red Lg/R ....... Light Green / Red Y/L ............. Yellow / Blue
B/W ......... Black / White Lg/W ....... Light Green / White Y/R ............. Yellow / Red
B/Y ......... Black / Yellow
