L8-S1
M9540Low Profile, WSM
HYDRAULIC SYSTEM
1. TROUBLESHOOTING
BI-SPEED TURN
W1013580
Symptom Probable Cause Solution
Reference
Page
Bi-Speed Turn Clutch
Slip
Operating pressure is low Adjust L3-S3
Bi-Speed turn solenoid Repair or replace L9-S11
Clutch disc or drive plate excessively worn Replace L3-S10, 12
Deformation of piston Replace L3-S10
Bi-Speed Turn Does
Not Rotate
Bi-Speed turn clutch malfunctioning Repair or replace L3-S10
4WD propeller shaft coupling disengaged Engage –
Operating Pressure
Is Low
Transmission oil improper or insufficient Replenish or change G-9
Relief valve malfunctioning Adjust or replace L3-S3
To Next Page
